Specificaties

Belangrijkste specificaties

Formaat ATX
CPU socket Socket 1155
Intel Coffee Lake compatible
Chipset Intel Z77
Type geheugen DDR3

Processor / Chipset

Formaat ATX
Ondersteunde processor(s) Intel Core i3 / i5 / i7
CPU socket Socket 1155
Intel Coffee Lake compatible
Type processorbus DMI
Chipset Intel Z77

Geheugen

Type geheugen DDR3
Type modules DIMM
ECC ondersteuning
Hoogst instelbare geheugensnelheid DDR3-3200
Aantal geheugenkanalen 2
Aantal geheugensloten 4
Intel XMP compatible
Maximum intern geheugen 32 GB
DDR DIMM-sloten 0
DDR2 DIMM-sloten 0
DDR2 SODIMM-sloten 0
DDR3 SODIMM-sloten 0
DDR3 DIMM-sloten 4

Uitbreidingssloten

Totaal aantal fysieke PCI-Express x16 sloten 2
PCI-Express x8 sloten 0
PCI-Express x4 sloten 0
Totaal aantal fysieke PCI-Express x1 sloten 2
Totaal aantal lanes alle PCI-Express x16 sloten 16
Mini PCI-Express aansluitingen 0
PCI-sloten 3

Multi-GPU

Nvidia SLI compatible
AMD CrossFire compatible
AMD CrossFire (2-way)
AMD CrossFire (4-way)

Connectiviteit

USB 2.0 - Totaal 10
USB 2.0 - extern 4
USB 3.0 (USB 3.2 Gen 1) - Totaal 4
USB 3.0 (USB 3.1 Gen 1) - Type-A poorten 2
IEEE 1394 controller -
IEEE 1394 - Aansluitingen achterzijde 0
Thunderbolt

Storage

Parallel ATA aansluitingen 0
Serial ATA aansluitingen (totaal) 6
Serial ATA 300 aansluitingen 4
Serial ATA 600 aansluitingen 2
eSATA aansluitingen 0
mSATA aansluitingen 0
Extra PATA (RAID) controller -
Extra SATA (RAID) controller -
RAID 0 ondersteuning
RAID 1 ondersteuning
RAID 5 ondersteuning
RAID 10 ondersteuning

Video

D-Sub (VGA) uitgang
DVI uitgang
HDMI uitgang
Aantal HDMI uitgangen 1
DisplayPort uitgang

Audio

Onboard audio - Kanalen 7.1
Onboard audio - Codec chip Realtek ALC887
Onboard audio - Codec type HDA
S/PDIF ingang
S/PDIF uitgang
Dolby Digital Live
DTS Connect
Bijgevoegde audiosoftware Creative X-Fi MB5

Netwerk

Aantal netwerkaansluitingen 1
LAN - Chip Realtek RTL8111E
LAN - Snelheid 1.000 Mbit/s
Bluetooth

Stroomcircuit

Totaal aantal chokes 6

Koeling / Overklokken

Fan aansluitingen (totaal) 4
Fan aansluitingen (4-pin) 3
Fan snelheid afhankelijk van temperatuur
Chipset koeler Passief
Maximale FSB/bClk frequentie 300 MHz
Max. CPU voltage 1,99 V
Max. VCCSA voltage 1,685 V
Max. geheugen voltage 2,135 V
North bridge / PCH 1.05V/1.09V voltage tweaking (maximaal) 1,685 V
Windows software voor overklokken meegeleverd
Multiplier instelbaar
PCI-Express klokfrequentie instelbaar
Heatsinks op cpu stroomvoorziening
CPU Turbo Modus uitschakelbaar
HyperThreading/SMT uitschakelbaar
Cores uitschakelbaar
PCI-Express sloten hardwarematig uitschakelbaar
Voltage meetpunten op moederbord

Overig

Onboard speaker
100% Solid Condensators
BIOS type EFI
Dual BIOS
Boot-menu in BIOS
Flash-programma in BIOS
BIOS profielen
Probleem diagnose
On-board Power / Reset switch
On-board Clear CMOS switch
Trusted Platform Module
BIOS-chip(s) vervangbaar
Lucid VirtuMVP software

Productcodes

SKU 90-MIBHT0-G0EAY0VZ, P8Z77-V LX, P8Z77-VLX, P8Z77VLX, 90-MIBHT0-G0EAY0MZ
EAN 4719543185858, 0610839185856, 4719543185865
Toegevoegd aan Hardware Info zaterdag 24 maart 2012

Testresultaten

Dit product is door Hardware Info getest op maandag 12 november 2012.

Benchmarks (Core i7 3770K, geïnt. graphics, Win7 x64)

PCMark 7 Computation Test 15.463
Testconfiguratie
  • Intel Core i7 3770K, 2x 2 GB DDR3
  • 1600, Geïntegreerde graphics, OCZ Vertex 4 128GB (Windows 7 x64)
3DMark Vantage (P) 4.182
Testconfiguratie
  • Intel Core i7 3770K, 2x 2 GB DDR3
  • 1600, Geïntegreerde graphics, OCZ Vertex 4 128GB (Windows 7 x64)
Cinebench 11.5 7,54
Testconfiguratie
  • Intel Core i7 3770K, 2x 2 GB DDR3
  • 1600, Geïntegreerde graphics, OCZ Vertex 4 128GB (Windows 7 x64)
Passmark 7 CPUmark 10.620,1
Testconfiguratie
  • Intel Core i7 3770K, 2x 2 GB DDR3
  • 1600, Geïntegreerde graphics, OCZ Vertex 4 128GB (Windows 7 x64)
Passmark 7 MemoryMark 1.543,3
Testconfiguratie
  • Intel Core i7 3770K, 2x 2 GB DDR3
  • 1600, Geïntegreerde graphics, OCZ Vertex 4 128GB (Windows 7 x64)
Stroomverbruik - 3DMark Vantage (gemiddeld) 72,0 W
Testconfiguratie
  • Intel Core i7 3770K, 2x 2 GB DDR3
  • 1600, Geïntegreerde graphics, OCZ Vertex 4 128GB (Windows 7 x64)
Stroomverbruik - Cinebench 11.5 (max) 95,3 W
Testconfiguratie
  • Intel Core i7 3770K, 2x 2 GB DDR3
  • 1600, Geïntegreerde graphics, OCZ Vertex 4 128GB (Windows 7 x64)
Stroomverbruik - Idle (gemiddelde 5 min.) 36,0 W
Testconfiguratie
  • Intel Core i7 3770K, 2x 2 GB DDR3
  • 1600, Geïntegreerde graphics, OCZ Vertex 4 128GB (Windows 7 x64)
Gebruikte BIOS-versie tijdens test 1306
Testconfiguratie
  • Intel Core i7 3770K, 2x 2 GB DDR3
  • 1600, Geïntegreerde graphics, OCZ Vertex 4 128GB (Windows 7 x64)
Standaard bClk waarde 100 MHz
Testconfiguratie
  • Intel Core i7 3770K, 2x 2 GB DDR3
  • 1600, Geïntegreerde graphics, OCZ Vertex 4 128GB (Windows 7 x64)

Audio test

Frequency response [+] 0,07 dB
Testconfiguratie
  • Rightmark Audio Analyzer
  • Loopback test
Frequency response [-] 0,13 dB
Testconfiguratie
  • Rightmark Audio Analyzer
  • Loopback test
Noise level 69,6 dB(A)
Testconfiguratie
  • Rightmark Audio Analyzer
  • Loopback test
Dynamic range 69,6 dB(A)
Testconfiguratie
  • Rightmark Audio Analyzer
  • Loopback test
Total Harmonic Distortion (THD) 0,0200 %
Testconfiguratie
  • Rightmark Audio Analyzer
  • Loopback test
Intermodulation Distortion (IMD) + Noise 0,087 %
Testconfiguratie
  • Rightmark Audio Analyzer
  • Loopback test
Stereo crosstalk 72 dB
Testconfiguratie
  • Rightmark Audio Analyzer
  • Loopback test
IMD+N (Swept frequency) 0,088 %
Testconfiguratie
  • Rightmark Audio Analyzer
  • Loopback test
