Specificaties

Belangrijkste specificaties

802.11-standaard 802.11n (Wi-Fi 4)
Geïntegreerd ADSL-modem

WiFi

Draadloos
802.11-standaard 802.11n (Wi-Fi 4)
Totale WiFi-snelheid 300 Mbit/s
Ondersteuning 2,4 GHz frequentieband
Ondersteuning 5 GHz freqentieband
Aantal antennes 4
Antennes intern/extern Intern
Verwisselbare antenne(s)
WMM (Wireless MultiMedia / 802.11e) compatible
Wireless Distribution System (WDS)

Bedraad

Aantal LAN-aansluitingen 4
LAN snelheid 1.000 Mbit/s

Internet

Ethernet WAN-aansluiting
Geïntegreerd ADSL-modem
RFC 2364 (PPP over ATM) compatible
RFC 1483 (Ethernet over ATM) compatible
PPPoE compatible
Installatie wizard

Beveiliging

64-bit WEP beveiliging
128-bit WEP beveiliging
256-bit WEP beveiliging
WPA beveiliging
WPA2 beveiliging
802.1X authenticatie
WLAN standaard beveiligd
WLAN beveiligd na installatie wizard
WLAN Mac filtering
1-knops beveiliging
WPS (Wi-Fi Protected Setup) ondersteuning

Router-mogelijkheden

Remote management
DHCP-server
Port forwarding / Virtual servers
Firewall
SPI Firewall
Poorten beperking lokale PC's
URL blokkering
Tijdsblokkering algemeen
Negeer ping van WAN
Waarschuwingen / log-bestanden via e-mail
DMZ (Demilitarized Zone)
Dynamic DNS cliënt
UPnP
VPN passthrough
Port triggering
Voorbeeld configuraties port triggering 0
QoS - Upstream beperken
QoS - Downstream beperken
QoS - Programma's/poorten prioriteren
QoS - PC's prioriteren
QoS - Lan Poorten Prioriteren
QoS - Mac-adres prioriteren

Overige hardware

Firmware tijdens test 1.0.12
Auto firmware check/update
USB printerserver
USB fileserver
USB webcam server
BitTorrent server
Chipset Ubicom IP7150u
Nederlandstalige GUI optie

Productcodes

SKU WL-350
EAN 8716502021499
Toegevoegd aan Hardware Info dinsdag 15 september 2009

Testresultaten

Dit product is door Hardware Info getest op vrijdag 13 november 2009.

WLAN Testconfiguratie 2009-2011 invoer

2P WLAN -> LAN i.c.m. Centrino 2,4 GHz [10m.] (run 1) 58,5 Mbit/s
Testconfiguratie
  • NetIQ Chariot i.c.m Intel Centrino notebook met Intel WiFiLink 5300
2P WLAN -> LAN i.c.m. Centrino 2,4 GHz [20m.] (run 1) 63,1 Mbit/s
Testconfiguratie
  • NetIQ Chariot i.c.m Intel Centrino notebook met Intel WiFiLink 5300
2P LAN -> WLAN i.c.m. Centrino 2,4 GHz [10m.] (run 1) 70,1 Mbit/s
Testconfiguratie
  • NetIQ Chariot i.c.m Intel Centrino notebook met Intel WiFiLink 5300
2P LAN -> WLAN i.c.m. Centrino 2,4 GHz [20m.] (run 1) 51,3 Mbit/s
Testconfiguratie
  • NetIQ Chariot i.c.m Intel Centrino notebook met Intel WiFiLink 5300
2P WLAN -> LAN i.c.m. Centrino 5 GHz [10m.] (run 1) 121,3 Mbit/s
Testconfiguratie
  • NetIQ Chariot i.c.m Intel Centrino notebook met Intel WiFiLink 5300
2P WLAN -> LAN i.c.m. Centrino 5 GHz [20m.] (run 1) 118,3 Mbit/s
Testconfiguratie
  • NetIQ Chariot i.c.m Intel Centrino notebook met Intel WiFiLink 5300
2P LAN -> WLAN i.c.m. Centrino 5 GHz [10m.] (run 1) 85,3 Mbit/s
Testconfiguratie
  • NetIQ Chariot i.c.m Intel Centrino notebook met Intel WiFiLink 5300
2P LAN -> WLAN i.c.m. Centrino 5 GHz [20m.] (run 1) 85,9 Mbit/s
Testconfiguratie
  • NetIQ Chariot i.c.m Intel Centrino notebook met Intel WiFiLink 5300

WLAN Testconfiguratie 2009-2011

2P WLAN -> LAN i.c.m. Centrino 2,4 GHz [10m.] (hoogste) 87,3 Mbit/s
Testconfiguratie
  • NetIQ Chariot i.c.m Intel Centrino notebook met Intel WiFiLink 5300
2P WLAN -> LAN i.c.m. Centrino 2,4 GHz [20m.] (hoogste) 91,5 Mbit/s
Testconfiguratie
  • NetIQ Chariot i.c.m Intel Centrino notebook met Intel WiFiLink 5300
2P LAN -> WLAN i.c.m. Centrino 2,4 GHz [10m.] (hoogste) 80,3 Mbit/s
Testconfiguratie
  • NetIQ Chariot i.c.m Intel Centrino notebook met Intel WiFiLink 5300
2P LAN -> WLAN i.c.m. Centrino 2,4 GHz [20m.] (hoogste) 68,4 Mbit/s
Testconfiguratie
  • NetIQ Chariot i.c.m Intel Centrino notebook met Intel WiFiLink 5300
2P WLAN -> LAN i.c.m. Centrino 5 GHz [10m.] (hoogste) 144,6 Mbit/s
Testconfiguratie
  • NetIQ Chariot i.c.m Intel Centrino notebook met Intel WiFiLink 5300
2P WLAN -> LAN i.c.m. Centrino 5 GHz [20m.] (hoogste) 146,3 Mbit/s
Testconfiguratie
  • NetIQ Chariot i.c.m Intel Centrino notebook met Intel WiFiLink 5300
2P LAN -> WLAN i.c.m. Centrino 5 GHz [10m.] (hoogste) 116,6 Mbit/s
Testconfiguratie
  • NetIQ Chariot i.c.m Intel Centrino notebook met Intel WiFiLink 5300
2P LAN -> WLAN i.c.m. Centrino 5 GHz [20m.] (hoogste) 138,7 Mbit/s
Testconfiguratie
  • NetIQ Chariot i.c.m Intel Centrino notebook met Intel WiFiLink 5300
2P WLAN -> LAN i.c.m. Centrino 2,4 GHz [10m.] (gemiddelde) 58,5 Mbit/s
Testconfiguratie
  • NetIQ Chariot i.c.m Intel Centrino notebook met Intel WiFiLink 5300
2P WLAN -> LAN i.c.m. Centrino 2,4 GHz [20m.] (gemiddelde) 63,1 Mbit/s
Testconfiguratie
  • NetIQ Chariot i.c.m Intel Centrino notebook met Intel WiFiLink 5300
2P LAN -> WLAN i.c.m. Centrino 2,4 GHz [10m.] (gemiddelde) 70,1 Mbit/s
Testconfiguratie
  • NetIQ Chariot i.c.m Intel Centrino notebook met Intel WiFiLink 5300
2P LAN -> WLAN i.c.m. Centrino 2,4 GHz [20m.] (gemiddelde) 51,3 Mbit/s
Testconfiguratie
  • NetIQ Chariot i.c.m Intel Centrino notebook met Intel WiFiLink 5300
2P WLAN -> LAN i.c.m. Centrino 5 GHz [10m.] (gemiddelde) 121,3 Mbit/s
Testconfiguratie
  • NetIQ Chariot i.c.m Intel Centrino notebook met Intel WiFiLink 5300
2P WLAN -> LAN i.c.m. Centrino 5 GHz [20m.] (gemiddelde) 118,3 Mbit/s
Testconfiguratie
  • NetIQ Chariot i.c.m Intel Centrino notebook met Intel WiFiLink 5300
2P LAN -> WLAN i.c.m. Centrino 5 GHz [10m.] (gemiddelde) 85,3 Mbit/s
Testconfiguratie
  • NetIQ Chariot i.c.m Intel Centrino notebook met Intel WiFiLink 5300
2P LAN -> WLAN i.c.m. Centrino 5 GHz [20m.] (gemiddelde) 85,9 Mbit/s
Testconfiguratie
  • NetIQ Chariot i.c.m Intel Centrino notebook met Intel WiFiLink 5300

Stroomverbruik

Stroomverbruik idle 5,8 W
Testconfiguratie
  • Testsysteem stroomverbruik
Stroomverbruik zenden 20 m. 6,9 W
Testconfiguratie
  • Testsysteem stroomverbruik

Testresultaten bedraad

Doorvoersnelheid LAN➜LAN 909 Mbit/s
Testconfiguratie
  • NetIQ Chariot. i.c.m. Intel 82566DM 10/100/1000 Mbit/s NIC
Doorvoersnelheid LAN➜LAN (zonder firewall) 912 Mbit/s
Testconfiguratie
  • NetIQ Chariot. i.c.m. Intel 82566DM 10/100/1000 Mbit/s NIC
Doorvoersnelheid WAN➜LAN 366 Mbit/s
Testconfiguratie
  • NetIQ Chariot. i.c.m. Intel 82566DM 10/100/1000 Mbit/s NIC
Doorvoersnelheid WAN➜LAN (zonder Firewall) 368 Mbit/s
Testconfiguratie
  • NetIQ Chariot. i.c.m. Intel 82566DM 10/100/1000 Mbit/s NIC
