Specificaties

Belangrijkste specificaties

Formaat Micro ATX
CPU socket Socket 1155
Intel Coffee Lake compatible
Chipset Intel H77
Type geheugen DDR3

Processor / Chipset

Formaat Micro ATX
Ondersteunde processor(s) Intel Core i3 / i5 / i7
CPU socket Socket 1155
Intel Coffee Lake compatible
Type processorbus DMI
Chipset Intel H77

Geheugen

Type geheugen DDR3
Type modules DIMM
Hoogst instelbare geheugensnelheid DDR3-2133
Aantal geheugenkanalen 2
Intel XMP compatible
Maximum intern geheugen 16 GB
DDR DIMM-sloten 0
DDR2 DIMM-sloten 0
DDR2 SODIMM-sloten 0
DDR3 SODIMM-sloten 0
DDR3 DIMM-sloten 2

Uitbreidingssloten

Totaal aantal fysieke PCI-Express x16 sloten 1
PCI-Express x8 sloten 0
PCI-Express x4 sloten 0
Totaal aantal fysieke PCI-Express x1 sloten 2
Mini PCI-Express aansluitingen 0
PCI-sloten 0

Multi-GPU

Nvidia SLI compatible
AMD CrossFire compatible

Connectiviteit

USB 2.0 - Totaal 8
USB 2.0 - extern 4
USB 3.0 (USB 3.2 Gen 1) - Totaal 4
USB 3.0 (USB 3.1 Gen 1) - Type-A poorten 2
IEEE 1394 controller -
IEEE 1394 - Aansluitingen achterzijde 0

Storage

Parallel ATA aansluitingen 0
Serial ATA aansluitingen (totaal) 4
Serial ATA 300 aansluitingen 2
Serial ATA 600 aansluitingen 2
eSATA aansluitingen 0
mSATA aansluitingen 0
Extra PATA (RAID) controller -
Extra SATA (RAID) controller -
RAID 0 ondersteuning
RAID 1 ondersteuning
RAID 5 ondersteuning
RAID 10 ondersteuning

Video

D-Sub (VGA) uitgang
DVI uitgang
HDMI uitgang
Aantal HDMI uitgangen 1
DisplayPort uitgang

Audio

Onboard audio - Kanalen 5.1
Onboard audio - Codec chip Realtek ALC662
Onboard audio - Codec type HDA
S/PDIF ingang
S/PDIF uitgang
Dolby Digital Live
DTS Connect
Bijgevoegde audiosoftware Creative X-Fi MB5

Netwerk

Aantal netwerkaansluitingen 1
LAN - Chip Realtek RTL8111F
LAN - Snelheid 1.000 Mbit/s
Bluetooth

Stroomcircuit

Totaal aantal chokes 5

Koeling / Overklokken

Fan aansluitingen (totaal) 2
Fan aansluitingen (4-pin) 2
Fan snelheid afhankelijk van temperatuur
Chipset koeler Passief
Max. geheugen voltage 1,85 V
Windows software voor overklokken meegeleverd
Multiplier instelbaar
PCI-Express klokfrequentie instelbaar
Heatsinks op cpu stroomvoorziening
CPU Turbo Modus uitschakelbaar
HyperThreading/SMT uitschakelbaar
Cores uitschakelbaar
PCI-Express sloten hardwarematig uitschakelbaar
Voltage meetpunten op moederbord

Overig

Onboard speaker
100% Solid Condensators
BIOS type AMI
Dual BIOS
Boot-menu in BIOS
Flash-programma in BIOS
BIOS profielen
Probleem diagnose
On-board Power / Reset switch
On-board Clear CMOS switch
Trusted Platform Module
BIOS-chip(s) vervangbaar
Lucid VirtuMVP software

Productcodes

SKU H77MXV
Toegevoegd aan Hardware Info woensdag 11 april 2012

Testresultaten

Dit product is door Hardware Info getest op dinsdag 29 mei 2012.

Benchmarks (Core i5 2500K, geïnt. graphics, Win7 x64)

SiSoft Sandra 2011 - CPU - Dhrystone 101,4 Gips
Testconfiguratie
  • Intel Core i5 2500K, 2x 2 GB DDR3
  • 1333, Geïntegreerde graphics, Western Digital Raptor 74 GB (Windows 7 x64)
SiSoft Sandra 2011 - CPU - Whetstone 48,55 GFlops
Testconfiguratie
  • Intel Core i5 2500K, 2x 2 GB DDR3
  • 1333, Geïntegreerde graphics, Western Digital Raptor 74 GB (Windows 7 x64)
SiSoft Sandra 2011 - Memory Bandwidth 17,3 GB/s
Testconfiguratie
  • Intel Core i5 2500K, 2x 2 GB DDR3
  • 1333, Geïntegreerde graphics, Western Digital Raptor 74 GB (Windows 7 x64)
Cinebench 10 5.728
Testconfiguratie
  • Intel Core i5 2500K, 2x 2 GB DDR3
  • 1333, Geïntegreerde graphics, Western Digital Raptor 74 GB (Windows 7 x64)
3DMark Vantage 1.755
Testconfiguratie
  • Intel Core i5 2500K, 2x 2 GB DDR3
  • 1333, Geïntegreerde graphics, Western Digital Raptor 74 GB (Windows 7 x64)
Stroomverbruik - Idle 39,9 W
Testconfiguratie
  • Intel Core i5 2500K, 2x 2 GB DDR3
  • 1333, Geïntegreerde graphics, Western Digital Raptor 74 GB (Windows 7 x64)
Stroomverbruik - Actief - Cinebench 10 (max) 96,8 W
Testconfiguratie
  • Intel Core i5 2500K, 2x 2 GB DDR3
  • 1333, Geïntegreerde graphics, Western Digital Raptor 74 GB (Windows 7 x64)
Stroomverbruik - Actief - 3DMark Vantage (max) 98,9 W
Testconfiguratie
  • Intel Core i5 2500K, 2x 2 GB DDR3
  • 1333, Geïntegreerde graphics, Western Digital Raptor 74 GB (Windows 7 x64)

Benchmarks (Core i5 2500K, Radeon HD 6850, Win7 x64)

SiSoft Sandra 2011 - CPU - Dhrystone 101,38 Gips
Testconfiguratie
  • Intel Core i5 2500K, 2x 2 GB DDR3
  • 1333, ATI Radeon HD 6850, Western Digital Raptor 74 GB (Windows 7 x64)
SiSoft Sandra 2011 - CPU - Whetstone 48,75 GFlops
Testconfiguratie
  • Intel Core i5 2500K, 2x 2 GB DDR3
  • 1333, ATI Radeon HD 6850, Western Digital Raptor 74 GB (Windows 7 x64)
SiSoft Sandra 2011 - Memory Bandwidth 17,4 GB/s
Testconfiguratie
  • Intel Core i5 2500K, 2x 2 GB DDR3
  • 1333, ATI Radeon HD 6850, Western Digital Raptor 74 GB (Windows 7 x64)
Cinebench 10 5.730
Testconfiguratie
  • Intel Core i5 2500K, 2x 2 GB DDR3
  • 1333, ATI Radeon HD 6850, Western Digital Raptor 74 GB (Windows 7 x64)
3DMark Vantage 14.201
Testconfiguratie
  • Intel Core i5 2500K, 2x 2 GB DDR3
  • 1333, ATI Radeon HD 6850, Western Digital Raptor 74 GB (Windows 7 x64)
Stroomverbruik - Idle 54,8 W
Testconfiguratie
  • Intel Core i5 2500K, 2x 2 GB DDR3
  • 1333, ATI Radeon HD 6850, Western Digital Raptor 74 GB (Windows 7 x64)
Stroomverbruik - Actief - Cinebench 10 (max) 112 W
Testconfiguratie
  • Intel Core i5 2500K, 2x 2 GB DDR3
  • 1333, ATI Radeon HD 6850, Western Digital Raptor 74 GB (Windows 7 x64)
Stroomverbruik - Actief - 3DMark Vantage (max) 138 W
Testconfiguratie
  • Intel Core i5 2500K, 2x 2 GB DDR3
  • 1333, ATI Radeon HD 6850, Western Digital Raptor 74 GB (Windows 7 x64)

Benchmarks (Core i7 3770K, geïnt. graphics, Win7 x64)

PCMark 7 Computation Test 15.808
Testconfiguratie
  • Intel Core i7 3770K, 2x 2 GB DDR3
  • 1600, Geïntegreerde graphics, OCZ Vertex 4 128GB (Windows 7 x64)
3DMark Vantage (P) 4.188
Testconfiguratie
  • Intel Core i7 3770K, 2x 2 GB DDR3
  • 1600, Geïntegreerde graphics, OCZ Vertex 4 128GB (Windows 7 x64)
Cinebench 11.5 7,46
Testconfiguratie
  • Intel Core i7 3770K, 2x 2 GB DDR3
  • 1600, Geïntegreerde graphics, OCZ Vertex 4 128GB (Windows 7 x64)
Passmark 7 CPUmark 10.440,6
Testconfiguratie
  • Intel Core i7 3770K, 2x 2 GB DDR3
  • 1600, Geïntegreerde graphics, OCZ Vertex 4 128GB (Windows 7 x64)
Passmark 7 MemoryMark 1.553,3
Testconfiguratie
  • Intel Core i7 3770K, 2x 2 GB DDR3
  • 1600, Geïntegreerde graphics, OCZ Vertex 4 128GB (Windows 7 x64)
Stroomverbruik - 3DMark Vantage (gemiddeld) 63,4 W
Testconfiguratie
  • Intel Core i7 3770K, 2x 2 GB DDR3
  • 1600, Geïntegreerde graphics, OCZ Vertex 4 128GB (Windows 7 x64)
Stroomverbruik - Cinebench 11.5 (max) 90 W
Testconfiguratie
  • Intel Core i7 3770K, 2x 2 GB DDR3
  • 1600, Geïntegreerde graphics, OCZ Vertex 4 128GB (Windows 7 x64)
Stroomverbruik - Idle (gemiddelde 5 min.) 25,2 W
Testconfiguratie
  • Intel Core i7 3770K, 2x 2 GB DDR3
  • 1600, Geïntegreerde graphics, OCZ Vertex 4 128GB (Windows 7 x64)
Gebruikte BIOS-versie tijdens test BB4F1P02
Testconfiguratie
  • Intel Core i7 3770K, 2x 2 GB DDR3
  • 1600, Geïntegreerde graphics, OCZ Vertex 4 128GB (Windows 7 x64)
Standaard bClk waarde 99,8 MHz
Testconfiguratie
  • Intel Core i7 3770K, 2x 2 GB DDR3
  • 1600, Geïntegreerde graphics, OCZ Vertex 4 128GB (Windows 7 x64)

Audio test

Frequency response [+] 0,27 dB
Testconfiguratie
  • Rightmark Audio Analyzer
  • Loopback test
Frequency response [-] 0,38 dB
Testconfiguratie
  • Rightmark Audio Analyzer
  • Loopback test
Noise level 87,5 dB(A)
Testconfiguratie
  • Rightmark Audio Analyzer
  • Loopback test
Dynamic range 87,4 dB(A)
Testconfiguratie
  • Rightmark Audio Analyzer
  • Loopback test
Total Harmonic Distortion (THD) 0,0036 %
Testconfiguratie
  • Rightmark Audio Analyzer
  • Loopback test
Intermodulation Distortion (IMD) + Noise 0,041 %
Testconfiguratie
  • Rightmark Audio Analyzer
  • Loopback test
Stereo crosstalk 83,5 dB
Testconfiguratie
  • Rightmark Audio Analyzer
  • Loopback test
IMD+N (Swept frequency) 0,035 %
Testconfiguratie
  • Rightmark Audio Analyzer
  • Loopback test
